Jbl 104 Aktif Referans Monitör Seti

Jbl 104 Aktif Referans Monitör Seti (JBL 104)

Marka : JBL
İndirim Oranı : %48 İndirim
KDV Dahil : $480.00
İndirimli : $208.00  + KDV
KDV Dahil : ₺8.257,22
:

Özellikler

  • Master and extension speaker sold as one set
  • Coaxial 4.5-inch (118 mm) contoured LF driver with integrated 7.5-inch (19 mm) soft-dome HF driver
  • Contoured low-frequency port
  • Integrated 60-watt Class D power amplifier; 30 watts distributed to each speaker
  • Acoustically optimized for desktop placement
  • Three sets of inputs allow connection with professional equipment, personal music players and consumer-level devices
  • Master monitor includes electronics for the extension monitor, minimizing wiring and clutter
  • Front-panel volume control
  • Front-panel headphone jack with speaker mute feature
  • Integrated power supply



Özellikler

Low Frequency Driver 4.5 in (118 mm)
High Frequency Driver 0.75 in (19 mm), soft dome
Crossover 1725 Hz, 1st order
Input Sensitivity 87 dB / 1 m
Power Amp 60 W (30 W each speaker), Class D
Maximum Continuous SPL @ 1 meter 89 dB
Maximum Peak SPL 102 dB
Maximum SPL 104 dB (momentary peak)
MAXIMUM PEAK INPUT LEVEL (-10dBV / +4dBu) +6 dBV / +20.3 dBu
Frequency Range 60 Hz - 20 kHz
SYSTEM DISTORTION CRITERIA <10% THD at maximum output with full compressor / limiter engagement
ELECTRICAL DISTORTION CRITERIA <0.2%THD @ 1 kHz, 2.83 VRMS output; <1% THD @ 1 kHz, full rated output
Signal to Noise Ratio 75 dBA (A-Weighted), 70 dBr (unweighted), relative to 2.83 VRMS output on HF
COVERAGE HORIZONTAL x VERTICAL 120º x 60º
Dimension (H x W x D) 9.72 in x 6.02 in x 4.88 in (247 mm x 153 mm x 124 mm)
Net Weight Master Monitor = 4.54 lb (2.06 kg); Slave Monitor = 3.81 lb (1.73 kg)
ENCLOSURE TYPE Ported
Enclosure Material ABS with metal grille
ENCLOSURE FINISH Matte black acrylic paint
Audio Output Connectors 1 x 3.5 mm (1/8") stereo headphone with auto speaker mute
Audio Input Connectors 2 x 1/4-inch (6.5 mm) balanced (+4 dBu); 2 x RCA (-10 dBV); 1 x 1/8-inch (3.5 mm) unbalanced (-10 dBV)
AC INPUT VOLTAGE 100 – 240 VAC (± 10%), 50/60 Hz
Current Draw 85 watts
